● APPLICATIONS :
Suitable for stirring, homogenizing, dispersing, etc. including medicines, dyed fabrics, adhesives, cosmetics, spices, coatings, pigments, chemical fibers, dyes, auxiliaries, general chemicals and other related chemical raw materials
● FEATURE :
1、Equipped with homogeneous dispersing blades, it can produce strong breaking force, impact and turbulent airflow.
2、Freely adjustable rotation-speed is available to maintain the best stirring effect.
3、All the liquid contact parts are in stainless steel, no need to worry about corrosion。
●SPECIFICATION :
HD-1HP、HD-2HP、HD-3HP、HD-5HP
HD-7.5HP、HD-10HP、HD-15HP、HD-20HP
◎ No container included; container sizes listed above are for reference only
Suitable for stirring, homogenizing, dispersing, etc. including medicines, dyed fabrics, adhesives, cosmetics, spices, coatings, pigments, chemical fibers, dyes, auxiliaries, general chemicals and other related chemical raw materials
● FEATURE :
1、Equipped with homogeneous dispersing blades, it can produce strong breaking force, impact and turbulent airflow.
2、Freely adjustable rotation-speed is available to maintain the best stirring effect.
3、All the liquid contact parts are in stainless steel, no need to worry about corrosion。
●SPECIFICATION :
HD-1HP、HD-2HP、HD-3HP、HD-5HP
| Model | HD-1HP | HD-2HP | HD-3HP | HD-5HP |
|---|---|---|---|---|
| Capacity | 20L | 30L | 50L | 100L |
| Speed | 1,800 rpm | 1,800 rpm | 1,800 rpm | 900 rpm |
| Motor | 1 HP | 2 HP | 3 HP | 5 HP |
| Motor (For Hydraulic Lift) |
----- | ----- | 1 HP | 1 HP |
| Acceptable Container Size |
W350 x L400mm | W350 x L400mm | W400 x L500mm | W570 x L900mm |
| Overall Size | W520 x L550 x H1600mm | W520 x L550 x H2000mm | W750 x L850 x H2700mm | W750 x L850 x H3200mm |
HD-7.5HP、HD-10HP、HD-15HP、HD-20HP
| Model | HD-7.5HP | HD-10HP | HD-15HP | HD-20HP |
|---|---|---|---|---|
| Capacity | 200L | 250L | 500L | 1000L |
| Speed | 900 rpm | 900 rpm | 900 rpm | 900 rpm |
| Motor | 7.5 HP | 10 HP | 15 HP | 20 HP |
| Motor (For Hydraulic Lift) |
1 HP | 2 HP | 2 HP | 2 HP |
| Acceptable Container Size |
W650 x L1100mm | W650 x L1350mm | Customized | Customized |
| Overall Size | W850 x L900 x H3500mm | W850 x L900 x H3600mm | Customized | Customized |
